7.8 m XCMG Scissor Lift — AS Series Wide-Platform
7.8 m maximum working height self-propelled scissor lift — the AS-series 7-meter variant of the XG0807AC. 5.8 m platform height, 230 kg lift capacity. AC drive electric. 'W' suffix denotes wider-platform build, 'AS' suffix aligns chassis specification with the 10-meter and 12-meter AS series siblings. 1,580 kg total weight (30 kg above the base XG0807AC), 1,360 mm wheelbase, 1.75 m outside turning radius. 4.5 km/h stowed driving speed, 0.8 km/h raised. 25 percent grade ability. Suited for fleet operators standardizing on the AS series across multiple height tiers.
The XCMG XG0807ACW-AS is a self-propelled scissor lift with 7.8 m maximum working height (5.8 m platform height) and 230 kg lift capacity — the wider-platform variant of the 7-meter AC sibling XG0807AC, fitted into the AS series with anti-skid drive features.
The XG0807ACW-AS sits in the AS family but with a smaller envelope than the 10/12-meter AS siblings. Same 7.8 m / 5.8 m working envelope as the XG0807AC base unit, same 230 kg capacity, but 30 kg additional deadweight (1,580 kg vs 1,550 kg) reflecting the wider-platform 'W' variant and AS chassis treatment. 4.5 km/h stowed driving speed, 0.8 km/h raised — same as the base XG0807AC. 25 percent grade ability. 1,360 mm wheelbase, 1.75 m outside turning radius. 71 mm ground clearance. Suited for fleet operators who already standardize on the AS series at 10/12 meters and want a 7-meter unit with matching specification and platform profile — common chassis families across the AS lineup reduce parts inventory carrying cost.
Five aspects of the XG0807ACW-AS that position it as the AS-series 7-meter wider-platform unit: envelope, wider-platform build, AC drive, AS-series alignment, and parts pool sharing.
7.8 m maximum working height and 5.8 m maximum platform height — same envelope as the base sibling XG0807AC. 230 kg rated lift capacity for 2-person crew plus tools. Sized for indoor mid-level access in the 5-to-6 meter platform range.
'W' suffix denotes wider-platform build vs the base XG0807AC — more deck area for crew movement and tool layout at platform height. Useful for work types where multiple crew members rotate positions or where tools and parts must be staged on the deck.
AC drive electric motor supports continuous-duty work cycles common in high-utilization rental fleets. Full electric drive control for fine positioning at height. 4.5 km/h stowed driving speed, 0.8 km/h raised — same transit speed as the base XG0807AC.
'AS' suffix aligns chassis specification with the 10-meter siblings XG1008AC-AS / XG1012AC-AS and the 12-meter XG1212AC-AS. Useful for fleet operators standardizing on the AS series — common AS-platform specifications across height tiers reduce parts inventory carrying cost.
Choose XG0807ACW-AS when the fleet is AS-standardized and the 7-meter envelope is needed. Step across to the base XG0807AC for narrower platform (and 30 kg weight saving). Step up to AS-series 10-meter siblings XG1008AC-AS / XG1012AC-AS for taller envelope. Genuine XCMG parts via me-equipment.com's authorized dealer channel.
| Parameter | Unit | Value |
|---|---|---|
| Max. working height | m | 7.8 |
| Max. platform height | m | 5.8 |
| Max. driving speed | km/h | 4.5 (stowed) / 0.8 (raised) |
| Min. turning radius (outside) | m | 1.75 |
| Min. ground clearance | mm | 71 |
| Max. lift capacity | kg | 230 |
| Max. grade ability | % | 25 |
| Wheel base | mm | 1360 |
| Total weight | kg | 1580 |
