33.9 Ton CAT 336 GC Excavator — Cat C7.1 / China Stage III, Tier 3 Equivalent
33.9-ton GC-series hydraulic excavator with a 6,800 kg counterweight. Cat C7.1 engine, 195 kW net power (ISO 9249), meets China Nonroad Stage III and equivalent to U.S. EPA Tier 3 / EU Stage IIIA. Reach 6.5 m boom, Reach 3.2 m stick, 1.88 m3 heavy duty bucket, 197 kN bucket digging force, 148 kN stick digging force. Maximum digging depth 7,520 mm, maximum reach at ground level 11,050 mm, maximum loading height 7,080 mm. 559 L/min main pump flow, 137 kN·m swing torque, 600 L fuel tank, 2,590 mm track gauge, 3,190 mm transport width.
The CAT 336 GC is a new 34-tonne crawler excavator for quarry operators, mining contractors and heavy civil crews who strip overburden, dig large foundations and canals, and load rigid haul trucks at the face. It sits one size class above the 330 GC, with a larger heavy duty bucket, a 6.8-tonne counterweight on a wider track gauge, and a fuel tank sized for long shifts away from the bowser.
Caterpillar states the engine meets China Nonroad Stage III and is equivalent to U.S. EPA Tier 3 and EU Stage IIIA. Product Link is standard, so hours, location and fuel burn can be checked remotely from a regional office, and the machine is rated for work at up to 3,300 m altitude. Plan road moves around the 3,190 mm transport width.
Machines are brand-new and ship from our yard with the complete export document pack. FOB China and CIF prices are quoted on request.
Five points that decide whether the 336 GC fits your fleet: rated power, emission level, bucket size against your haul trucks, transport width and undercarriage, and service cost over 12,000 hours.
The published specification lists a Cat C7.1 engine, 7.1 L, 105 mm bore x 135 mm stroke, at 195 kW net (ISO 9249) and 195 kW per ISO 14396. Two modes, Power and Smart; Smart mode lowers power when the dig does not need it. Caterpillar reports 5% better fuel efficiency than the 336D2 in similar applications.
Caterpillar states the engine meets China Nonroad Stage III and is equivalent to U.S. EPA Tier 3 and EU Stage IIIA. Biodiesel up to B20 and bio hydraulic oil are accepted. Two levels of fuel filtration, 52 °C ambient cooling, -18 °C cold start and an altitude rating of 3,300 m suit high, hot and remote mine sites.
Reach 6.5 m boom and Reach 3.2 m stick with a 1.88 m3 heavy duty bucket: 7,520 mm digging depth, 11,050 mm reach at ground level, 7,080 mm loading height, 197 kN bucket and 148 kN stick digging force (ISO). 559 L/min at 35,000 kPa and 137 kN·m swing torque. Stick options of 2.8 m and 3.9 m and a 6.18 m Mass boom are listed.
Standard undercarriage with 4,590 mm track length, 2,590 mm gauge and a 6,800 kg counterweight; 600-850 mm triple grouser shoes are listed. Transport width is 3,190 mm and shipping length 11,170 mm, so road moves need an oversize-load check in most markets. Grease-sealed track pins and a sloped track frame reduce wear from mud and debris.
Caterpillar calculates up to 20% lower maintenance cost than the 336F over 12,000 machine hours through extended intervals: 1,000-hour engine oil with Cat oil, filters and S·O·S sampling, and a 3,000-hour hydraulic oil filter. Product Link reports hours, location, fuel use and machine health to VisionLink. Cat One Key, remote disable and a lockable fuel drain compartment deter theft on unattended sites.
| Parameter | Unit | Value |
|---|---|---|
| Net power - ISO 9249 | kW | 195 |
| Engine power - ISO 14396 | kW | 195 |
| Engine model | - | Cat C7.1 |
| Bore | mm | 105 |
| Stroke | mm | 135 |
| Displacement | L | 7.1 |
| Biodiesel capability | - | Up to B20 |
| Emission standard | - | Meets China Nonroad Stage III / equivalent to U.S. EPA Tier 3 and EU Stage IIIA |
| Main system - max flow | L/min | 559 |
| Max pressure - equipment | kPa | 35,000 |
| Max pressure - travel | kPa | 35,000 |
| Max pressure - swing | kPa | 28,000 |
| Swing speed | r/min | 8.74 |
| Max swing torque | kN·m | 137 |
| Operating weight | kg | 33,900 |
| Counterweight | kg | 6,800 |
| Fuel tank | L | 600 |
| Cooling system | L | 19 |
| Engine oil | L | 20 |
| Swing drive - each | L | 18 |
| Final drive - each | L | 8 |
| Hydraulic system incl. tank | L | 373 |
| Hydraulic tank | L | 161 |
| Boom | m | Reach 6.5 |
| Stick | m | Reach 3.2 |
| Bucket | m3 | HD 1.88 |
| Shipping height - top of cab | mm | 3,170 |
| Handrail height | mm | 3,160 |
| Shipping length | mm | 11,170 |
| Tail swing radius | mm | 3,530 |
| Counterweight clearance | mm | 1,250 |
| Ground clearance | mm | 510 |
| Track length | mm | 4,590 |
| Length to center of rollers | mm | 3,610 |
| Track gauge | mm | 2,590 |
| Transport width | mm | 3,190 |
| Max digging depth | mm | 7,520 |
| Max reach at ground level | mm | 11,050 |
| Max cutting height | mm | 10,300 |
| Max loading height | mm | 7,080 |
| Min loading height | mm | 2,580 |
| Max depth cut for 2,440 mm (8 ft) level bottom | mm | 7,360 |
| Max vertical wall digging depth | mm | 5,660 |
| Bucket digging force - ISO | kN | 197 |
| Stick digging force - ISO | kN | 148 |
