XCMG XPY1300D Movable Cone Crushing Station

Multi-cylinder hydraulic cone crusher head with dedicated hydraulic lubrication system pressurising mantle bearings. Multi-cylinder layout distributes crushing force across several support cylinders rather than a single column, lifting the load envelope above a single-cylinder cone of equivalent throughput.

Self-adaptive engine power matching reduces diesel engine output during partial-load chamber conditions instead of running flat-out. Operating-cost effect over a sustained quarry shift where feed presentation is uneven. 1050 L fuel tank supports extended shift runs between refills on remote pit sites.

Curb weight 72.76 t with the material-return conveyor, 62.02 t without — a 10.74 t difference. The return conveyor recycles oversize discharge back to the crusher inlet, lifting net product yield and reducing waste haul. Specify with conveyor for closed-loop secondary/tertiary work; specify without for open-circuit lines feeding a downstream screen.

140–635 t/h rated handling capacity covers secondary and tertiary positions in mobile aggregate setups. Typically fed by a primary XPE jaw station or XGE jaw crusher producing the upstream coarse feed. Suited for highly abrasive natural stones — pairs with XGY single-cylinder cone crushers for fixed-plant tertiary work, or runs stand-alone in mobile lines.

1050 L diesel fuel tank, 260 L hydraulic oil tank, 400 L lubrication oil tank. Total on-board fluid capacity sized for long shifts at remote quarry or pit sites where service trucks are not on-call.
