6-ton topless (flat-top) tower crane in the XCMG S-series. 80 t·m rated lifting moment, 56 m maximum working range with 1.03 t tip load. Free-standing 39 m without external tie-back; with climbing attachment, total operational height reaches 199 m — supporting commercial and residential builds up to roughly 55-60 floors. 470 m wire rope drum capacity. Sibling variant: XGT5610E-6S1 (40 m free-standing height, 199.6 m attached, same lift envelope).
The XCMG XGT5610D-6S1 is a 6-ton topless (flat-top) tower crane in the S-series — built for housing construction, bridge work, nuclear and thermal power projects, and large venue sites where airspace constraints rule out elevated jib designs.
The XGT5610D-6S1 carries 80 t·m rated lifting moment with a 56 m maximum working range and 1.03 t tip load. Free-standing height 39 m without external tie-back; with climbing attachment, total operational height reaches 199 m — supporting commercial and residential builds up to roughly 55-60 floors. 470 m wire rope drum capacity. The horizontal flat-top jib design lowers the overall vertical envelope versus luffing-jib cranes — useful on sites under airport approach corridors, helicopter operations zones, or with maximum-height restrictions. Standard fit where multiple tower cranes cluster on the same site and overlap is managed by horizontal radius rather than vertical jib elevation. The S-series control architecture inherits conventions from XCMG truck cranes, shortening cross-training for crews running mixed mobile and tower fleets.
