XCMG XGS20K Telescopic Boom Lift

20.5 m max working height, 18.5 m max platform height, 13.2 m max horizontal working range. 8,500 kg dead weight — 32 percent lighter than the next-up XGS22K (12,460 kg) and well below the 12 t mark for many rental-spec trailer GVWR limits. Reduces transit cost and trailer requirements for rental fleet operators.

300 kg unlimited platform capacity — no dual-mode (limited/unlimited) like the larger 22+ m K-series. Two occupants — smaller 1,830 × 760 × 1,150 mm working platform vs the 2,400 mm wider platforms on the 22+ m K-series. Suits smaller crew + handheld tool work patterns. ±160° platform rotation, 360° continuous turntable rotation.

3,100 mm inside / 5,000 mm outside turning radius — tightest in the XGS metric series (vs 3,195 mm XGS22K, 3,200 mm XGS18K). 2,500 mm wheelbase. Suits congested factory work and tight indoor industrial corridors.

Working slope tolerance X-5° / Y-5° — wider than the 22+ m K-series at X-3° / Y-3°. Allows operation on slightly more uneven indoor floors and outdoor work surfaces. Telescopic boom luffing -5° to +76°. 45% (24°) max gradeability, 300 mm ground clearance.

2,500 mm wheelbase shared with XGS22K — chassis-side parts compatibility for fleet operators running both 20 m and 22 m XCMG telescopic boom lifts. 7,400 × 2,270 × 3,000 mm transport configuration (narrower 2,270 mm transport width than the K-series 2,490 mm). Lower inventory carrying cost across the small-K range.
