Electric self-propelled telescopic boom lift, 20.5 m maximum working height and 18.5 m platform height. 13.2 m maximum horizontal working range. 300 kg unlimited lift capacity — 2 occupants plus tools across the full envelope without zone derating. 8.35 ton unit weight. 4.8 km/h stowed drive speed, 45 percent gradeability, 1.85 m flying jib. Non-marking off-road tires and axle balancing as standard — drives outdoor sites and operates indoors with zero emission and low noise.
The XCMG XGS20ACK is an electric self-propelled telescopic boom lift in the 20-meter working height class. Maximum platform height is 18.5 m, working height 20.5 m, horizontal working range 13.2 m. Lift capacity is 300 kg unlimited — 2-person platform with full envelope rating, no zone derating. Unit weight is 8.35 tons; stowed dimensions 9800 x 2490 x 2640 mm, transport profile 7400 x 2270 x 3000 mm.
Drive speed is 4.8 km/h stowed and 0.6 km/h up or extended. Four-wheel drive base climbs 45 percent (24 degrees) grades with 300 mm ground clearance. Turning radius 3.1 m inside / 5.0 m outside. Telescopic boom luffing range -5 to +76 degrees, with a 1.85 m flying jib at -65 to +70 degrees. Turntable rotation 360 degrees, platform rotation 160 degrees. 1830 x 760 x 1150 mm platform.
Standard fit of non-marking off-road tires plus axle balancing system — same machine drives outdoor sites and operates inside finished interiors. Zero emission and low noise. Sibling XGS20ACK-LI shares the working envelope with a lithium-ion battery pack option.
