Electric self-propelled telescopic boom lift, 18.28 m maximum working height and 16.28 m platform height. 12.05 m maximum horizontal working range. 300 kg unlimited lift capacity — 2 occupants plus tools across the full envelope without zone derating. 8.2 ton unit weight. 5.5 km/h stowed drive speed, 45 percent gradeability, 1.42 m flying jib. Non-marking off-road tires and axle balancing as standard — drives outdoor sites and operates indoors with zero emission and low noise.
The XCMG XGS18ACK is an electric self-propelled telescopic boom lift sized for the 18-meter working height class. Maximum platform height is 16.28 m, maximum working height 18.28 m, and horizontal working range 12.05 m. Lift capacity is 300 kg unlimited — the platform carries up to 2 occupants with tools without zone-based capacity restrictions across the working envelope. Unit weight is 8.2 tons; stowed dimensions are 9150 x 2320 x 2520 mm, fitting standard 20-foot container transport profiles.
Drive speed is 5.5 km/h stowed and 0.6 km/h elevated. The four-wheel drive base climbs 45 percent (24 degrees) grades and turns inside a 3.2 m / 4.7 m turning radius. Telescopic boom luffing range is -8 to +73.5 degrees, with a 1.42 m flying jib extending to -60 / +70 degrees. Turntable rotation is 360 degrees continuous, platform rotation 160 degrees.
The ACK variant runs on non-marking off-road tires with an axle balancing system as standard, enabling outdoor site driving and indoor zero-emission, low-noise, non-marking operation in finished interiors. Sibling XGS18ACK-LI shares the same envelope with a lithium-ion battery pack option.
