Top of the XCMG entry/mid jaw-crusher line. 760 × 1150 mm feed inlet (tall-and-narrow deep chamber), 70–200 mm discharge opening, 165–520 t/h productivity. 132 kW motor, 260 r/min main shaft. 22.67 t machine weight, 3634 × 2395 × 2869 mm footprint. Built for primary crushing in mining, water engineering, metallurgy and aggregate lines — deeper chamber gives more material residence time and a steeper nip angle, lifting reduction ratio per pass.
The XCMG XGE0812 is the top-end model in the XCMG entry/mid jaw-crusher line. Built for primary crushing in mining, water engineering, metallurgy, and building-material aggregate lines. 760 × 1150 mm feed inlet (tall-and-narrow chamber), 70–200 mm discharge opening, 165–520 t/h productivity. 132 kW motor, 260 r/min main shaft. 22.67 t machine weight, 3634 × 2395 × 2869 mm footprint.
The tall-and-narrow 760 × 1150 mm chamber suits primary crushing of regular-shaped or pre-screened feed where vertical chamber depth matters more than mouth width — different geometry profile from the XGE0810 sibling (1060 × 700 mm wide-mouth). The deeper chamber gives more material residence time and a steeper nip angle, lifting reduction ratio per pass.
In the XCMG jaw line the XGE0812 sits above the XGE0810 (1060 × 700 mm, 110 kW, 17.05 t) and XGE0609 (580 × 930 mm, 90 kW, 12.86 t). 132 kW motor and 22.67 t machine weight are the top of the entry/mid XGE range. Fits 200–500 t/h stationary aggregate plants where chamber depth and reduction ratio dictate output sizing. Pairs upstream of XGY single-cylinder cone crushers and XGF impact crushers in plant lines. Genuine XCMG parts and service available through me-equipment.com's authorized dealer channel.
