XCMG XGA26K Articulating Boom Lift

256 kg lift capacity at all reach positions — no restricted/unrestricted split. The sibling XGA26K1 splits load (256 kg restricted / 150 kg unrestricted) for lighter chassis weight; the XGA26K trades 1.6 t of extra chassis weight (18,100 kg vs 16,500 kg) for a flat capacity rating. Simpler operator load planning — the platform always carries up to 256 kg regardless of boom position.

26.6 m working height, 24.6 m platform height, 19.5 m working range, 8.7 m up-and-over clearance. The 8.7 m up-and-over quantifies the negative-luff envelope — the boom can clear obstacles 8.7 m wide before reaching the work area on the far side. Sized for refinery, petrochemical, multi-story fit-out, and large-span steel structure erection.

Integrated motor-and-reducer walking unit with fast and slow drive speeds for varied site conditions. Fast for transit between work positions across open ground; slow for fine positioning on tight sites or when the boom is raised. Operator switches modes from the platform console without external adjustment.

Walking mechanism includes a clutch device that disengages the drive train, allowing the chassis to be towed in case of drive system failure. Reduces site downtime — a stalled boom lift can be moved off the work area for repair rather than blocking the site until parts arrive.

1,850 mm flying jib with -65 to +70 degree luffing range extends platform position beyond the second boom. 160-degree platform rotation supports operator orientation when the jib places the platform off-axis. 360-degree continuous turntable rotation for unrestricted slew around central features.
