Intelligent asphalt distributor on a Sinotruk ZZ1047D3815C145 4×2 chassis. 4.2 m³ asphalt tank, 4 m maximum spraying width, 0.2–3.0 kg/m² spraying rate held constant by the controller regardless of vehicle speed. Sprays emulsified, diluted, hot, and modified asphalt for prime coat, tack coat, and upper/lower seal coats on highways, all grades of roads, and municipal streets. Yuchai YN4102QBZL engine (85 kW). 5,430 kg curb weight, 6,400 × 2,100 × 2,540 mm overall — step up from the XLS305A entry tier within the XLS family.
The XCMG XLS505A is a 4 m spraying-width asphalt distributor on a Sinotruk ZZ1047D3815C145 4×2 chassis with a 4.2 m³ asphalt tank. It sprays emulsified, diluted, hot, and modified asphalt at controlled rate across the 0.2–3.0 kg/m² range — the controller holds spraying density independent of truck speed so output per square meter stays within target on long passes and short pulls.
The 85 kW Yuchai YN4102QBZL engine and 5,430 kg curb weight match municipal and county-road maintenance work running prime coat, tack coat, and seal coat layers on a daily rotation. Overall dimensions are 6,400 × 2,100 × 2,540 mm. The 4 m spraying width covers single-lane work plus shoulder strip — wider than the 3.5 m XLS305A but smaller than the 4.5 m XLS705A and the 6 m highway-class units.
Choose XLS505A when project geometry needs slightly more width than the entry-tier XLS305A but the daily output target doesn't justify the 7 m³ tank of the XLS705A. Genuine XCMG parts and service available through me-equipment.com's authorized dealer channel.
