XCMG XD90 Light Tandem Vibratory Roller

Both drums drive and both drums vibrate independently. Independent front and rear drum vibration lets the operator select drum-by-drum vibration in patch work or maintain even compaction on transitions. Tandem layout fits small lift thickness work where a single-drum roller is oversized. Small amplitude, high frequency vibration profile sized for thin-lift asphalt surface.

Kubota 16.1 kW engine. EU Stage V and EPA Tier 4 Final emission compliance — fits EU, UK, US, Canada, and other regulated markets where Stage V and T4F gate equipment entry. Kubota is a well-established compact-equipment engine platform with broad parts and service network. Stage V / T4F regulated-market access is rare in this light class — relevant for rental fleets operating across multiple jurisdictions.

Foldable Roll-Over Protective Structure folds down: standing height 2,475 mm, folded height 1,580 mm. Lets the roller pass under low overhead clearance — urban tunnel approaches, small driveway extensions, parking-deck entries — and load onto small flatbed trucks for daily transit between maintenance sites without low-bed dispatch.

Working width 900 mm, vibration frequencies 45 Hz and 62 Hz (small amplitude, high frequency). Sized for compaction on newly built pavement asphalt top layer, thinner stable-soil pavement, and road maintenance patches. Suited to municipal maintenance crews, highway-custody contractors patching shoulder and lane work, and small paving outfits where the 12-13 t XD120 / XD135T class is oversized.

Lightest tandem roller in the XCMG XD-series light compaction line. Below the 12 t XD120 / XD120R / XD120VT siblings and far below the heavier XD135T. Fits rental fleets, municipal maintenance contractors, and small paving outfits where the upper-class machines are oversized for shoulder, patch, and small-area work.
