Feature Parameter Back to the list --Check for other models-- XM35 XM50 XM50E XM100E XM101 XM101E XM101K XM120F XM130K XM200 XM200E XM200K Model 　 XM101 　 Max. milling with mm 1020 　 Max. milling depth mm 120 Milling wheel Number of tools 　 84 Drum diameter with tools mm 660 Engine Model 　 D6114 Rated power kW 125 Rated speed rpm 2200 Specifications Operating speed m/min 0～13 Travel speed km/h 0～13 Ground clearance % ≥20 Ground clearance mm ≤120 Operating weight kg 14500 Volume Fuel tank L 210 Hydraulic oil tank L 160 Water tank L 360 Conveyor Width mm 400 Measurement Overall machinery LxWxH mm 4583×2294×3130 Conveyor LxWxH mm 6428×700×610 Travel mode 　 Tire
