XCD160A                                                    Home>New equipment>Crane products>Tower crane

Feature

Parameter

Back to the list
Jib Fall Range 3.5～20 22 25 27 30 32 35 37 40 42 45 47 50
50 IV Load 10 8.7 7.5 6.8 6.0 4.5 5.5 4.9 4.1 3.8 3.5 3.2 3.0
II 5 4.9 4.1 3.8 3.5 3.2 3.0

Jib Fall Range 3.5～20 22 25 27 30 32 35 37 40 42 45
45 IV Load 10 9.0 7.7 7.0 6.2 5.7 5.1 4.7 4.2 4.0 3.6
II 5 4.7 4.2 4.0 3.6

Jib Fall Range 3.5～20 22 25 27 30 32 35 37 40
40 IV Load 10 9.1 7.8 7.1 6.2 5.7 5.1 4.8 4.3
II 5 4.8 4.3

Jib Fall Range 3.5～20 22 25 27 30 32 35
35 IV Load 10 9.2 8.0 7.2 6.4 5.9 5.3
II 5

Jib Fall Range 3.5～20 22 25 27 30
30 IV Load 10 9.4 8.1 7.3 6.5
II 5
