| Model | SQ4ZK2 | Unit |
|---|---|---|
| Max Lifting Moment | 8.4 | t.m |
| Max Lifting Capacity | 4000 | kg |
| Recommend Power Needed At Recommend Oil Flow | 14 | kw |
| Max Oil Flow of Hydraulic System | 25 | L/min |
| Rated Pressure Of Hydraulic System | 26 | MPa |
| Oil Tank Capacity | 60 | L |
| Rotation Angle | 370 | 。 |
| Crane Weight | 1200 | kg |
| Installation Space | 850 | mm |
| Choice of Chassis | EQ1092FJ1东风；EQ1092FJ东风；DFL1120B D530东风；EQ1081GJ12D5东风；HFC1132KR1K3江淮；LZ1120LAPT东风柳汽；HFC1083K103R1D江淮；EQ1092F3GJ1东风；EQ5121GFJ东风； | |
| Working radius (m) | 2.1 | 4.15 | 5.8 | 7.3 |
| Lifting capacity (kg) | 4000 | 1840 | 1260 | 920 |
