Model SQ25ZK6Q Unit
Max Lifting Moment 62.5 t.m
Max Lifting Capacity 25000 kg
Recommend Power Needed At Recommend Oil Flow 50 kw
Max Oil Flow of Hydraulic System 80 L/min
Rated Pressure Of Hydraulic System 31.5 MPa
Oil Tank Capacity 300 L
Rotation Angle (360°)All Rotation 。
Crane Weight 7945 kg
Installation Space 3000 mm
Choice of Chassis 专用汽车底盘（无国家公告）
SQ25ZK6Q Lifting capability diagram
Working radius(m) 2.5 4.22 5.93 7.74 9.59 11.48 13.43 15.45
Lifting capacity(kg) 25000 14000 9000 6500 5000 4000 3000 2500
The lifting capability diagram with optional Jib
Working radius(m) 18.63 20.31 22.02 23.76 25.53
Lifting capacity(kg) 1050 950 800 700 600
