Model SQ12SK3Q Unit
Max Lifting Capacity 12000 kg
Max Lifting Moment 30 T.M
Recommend Power 30 kw
Max Oil Flow of Hydraulic System 63 L/min
Max Pressure of Hydraulic System 26 MPa
Oil Tank Capacity 160 L
Rotation Angle All Rotation
Crane Weight 4200 kg
Installation Space 1300 mm
Choice of Chassis DFL1250A9 东风天龙；DFL1311A3东风 ；CA1240PK2L7T4EA81青岛；EQ5201GFJ6东风；BJ1317VNPJJ-S5北汽福田；BJ5253ZKPJJ北汽福田；DFL1253AX东风；
SQ12SK3Q Lifting capability diagram
Working radius (m) 2.5 4.8 7 9 12.5
Lifting capacity (kg) 12000 6000 3500 2700 1800
