Main technical data in travel configuration Category Item Parameter Dimension Overall length mm 9700 Overall height mm 3800 Overall width mm 2500 Wheel base mm 5000 Track mm 1940 mm 1860 Weight kg 13200 Wheel base kg 4400 kg 8800 kg 13500 kg 4750 kg 8750 Travel Max．travel speed km/h ≥85 Min．turning diameter m ≤18 Approach angle ° ≥25° Departure angle ° ≥10° Braking distance(at 30km/h) m ≤10 Min．ground clearance mm 248 Fuel consumption of per 100km L ≤23 Max．gradeability % ≥28% Category Item Main Rated working height m 25 Max．working radius m 15 Outrigger span(longitudinal×lateral) m 5.2×4.5 Fire pump rated reach L／s 32～40 Fire pump rated outlet pressure MPa 1.0～1.3 Water monitor L／s 32 m ≥50 m ≥45 Working speed Boom deploying time S ≤140 Outrigger extending time S ≤40 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
